UV sterilizers play a crucial role in water treatment facilities by providing an effective method for disinfecting water. They are often used as part of a multi-barrier approach to ensure the safety and purity of drinking water.
In water treatment facilities, UV sterilizers are typically installed in the final stage of the treatment process, after other filtration and chemical treatment methods have been applied. The purpose of UV sterilization is to target and eliminate any remaining microorganisms that may have survived previous treatment steps.
When water passes through a UV sterilizer, it is exposed to UV-C light generated by special lamps or LEDs. This light penetrates the cells of bacteria, viruses, and other pathogens present in the water, disrupting their DNA or RNA and preventing them from reproducing. As a result, the microorganisms are effectively neutralized, rendering the water safe for consumption.
UV sterilization offers several advantages in water treatment facilities:
Chemical-free disinfection: Unlike traditional disinfection methods that rely on chemicals such as chlorine, UV sterilization does not introduce any chemical byproducts into the water. This makes it a preferred option for facilities aiming to reduce chemical usage or for those treating sensitive water sources.
High effectiveness: UV sterilizers are highly effective against a wide range of pathogens, including bacteria, viruses, and protozoa. They provide a high level of disinfection, typically achieving 99.9% or greater inactivation of microorganisms.
Quick and continuous operation: UV sterilizers provide rapid disinfection without the need for contact time or storage. As soon as the water passes through the UV chamber and is exposed to the UV-C light, the disinfection process begins. This enables continuous and on-demand water treatment.
Environmentally friendly: UV sterilization is considered an environmentally friendly method of disinfection since it does not generate harmful disinfection byproducts or contribute to the formation of chlorine-resistant organisms.
It's important to note that UV sterilization is most effective against free-floating microorganisms in the water. It may not be as effective against certain types of parasites, such as Cryptosporidium, that are protected by a cyst or oocyst form. Therefore, UV sterilizers are often used in conjunction with other water treatment processes to provide comprehensive disinfection.
Overall, UV sterilizers are a valuable tool in water treatment facilities, helping to ensure the delivery of safe and clean drinking water to communities. Their reliable and efficient disinfection capabilities make them a vital component of modern water treatment processes.
UV sterilizers play a crucial role in water treatment facilities by providing an effective method for disinfecting water. They are often used as part of a multi-barrier approach to ensure the safety and purity of drinking water.
In water treatment facilities, UV sterilizers are typically installed in the final stage of the treatment process, after other filtration and chemical treatment methods have been applied. The purpose of UV sterilization is to target and eliminate any remaining microorganisms that may have survived previous treatment steps.
When water passes through a UV sterilizer, it is exposed to UV-C light generated by special lamps or LEDs. This light penetrates the cells of bacteria, viruses, and other pathogens present in the water, disrupting their DNA or RNA and preventing them from reproducing. As a result, the microorganisms are effectively neutralized, rendering the water safe for consumption.
UV sterilization offers several advantages in water treatment facilities:
Chemical-free disinfection: Unlike traditional disinfection methods that rely on chemicals such as chlorine, UV sterilization does not introduce any chemical byproducts into the water. This makes it a preferred option for facilities aiming to reduce chemical usage or for those treating sensitive water sources.
High effectiveness: UV sterilizers are highly effective against a wide range of pathogens, including bacteria, viruses, and protozoa. They provide a high level of disinfection, typically achieving 99.9% or greater inactivation of microorganisms.
Quick and continuous operation: UV sterilizers provide rapid disinfection without the need for contact time or storage. As soon as the water passes through the UV chamber and is exposed to the UV-C light, the disinfection process begins. This enables continuous and on-demand water treatment.
Environmentally friendly: UV sterilization is considered an environmentally friendly method of disinfection since it does not generate harmful disinfection byproducts or contribute to the formation of chlorine-resistant organisms.
It's important to note that UV sterilization is most effective against free-floating microorganisms in the water. It may not be as effective against certain types of parasites, such as Cryptosporidium, that are protected by a cyst or oocyst form. Therefore, UV sterilizers are often used in conjunction with other water treatment processes to provide comprehensive disinfection.
Overall, UV sterilizers are a valuable tool in water treatment facilities, helping to ensure the delivery of safe and clean drinking water to communities. Their reliable and efficient disinfection capabilities make them a vital component of modern water treatment processes.
MODEL | CONNECTION | MAXIMUM FLOW | BODY DIAMETER | NO. OF LAMPS | POWER |
INCH | m³/h | DN | PCS | W | |
BTZW-20 | 3/4 | 4 | 50 | 1 | 40 |
BTZW-25 | 1 | 5 | 65 | 1 | 40 |
BTZW-32 | 1.2 | 6 | 65 | 1 | 80 |
BTZW-40 | 1.5 | 7 | 65 | 1 | 80 |
BTZW-50 | 2 | 10 | 80 | 1 | 120 |
BTZW-65 | 2.5 | 12 | 100 | 2 | 240 |
BTZW-80 | 3 | 20 | 100 | 2 | 240 |
BTZW-100 | 4 | 30 | 125 | 3 | 360 |
BTZW-125 | 5 | 40 | 150 | 4 | 480 |
BTZW-150 | 6 | 90 | 200 | 7 | 840 |
BTZW-150 | 6 | 120 | 200 | 8 | 960 |
BTZW-200 | 8 | 150 | 300 | 9 | 1350 |
BTZW-200 | 8 | 200 | 300 | 10 | 1500 |
BTZW-250 | 10 | 250 | 350 | 11 | 1650 |
BTZW-250 | 10 | 300 | 350 | 13 | 1800 |
BTZW-300 | 12 | 350 | 400 | 14 | 1950 |
BTZW-300 | 12 | 400 | 400 | 16 | 2100 |
BTZW-350 | 14 | 500 | 500 | 20 | 3000 |
